Ultrafuse ABS

BASF-UF-ABS-BLACK-175-750
24.75 € 24.75 €
Tax excl.
Diameter
Format
Colour
Quantity

In stock 4 units available for immediate shipping.
units available for shipping in 3 - 5 days
Available for shipment within 3 - 5 days

Product temporarily out of stock with these characteristics. Select another combination.

Product temporarily out of stock with these characteristics. Select another combination.

We notify you when it will be available:

Approximate delivery date: Wednesday 16 October

The BASF Ultrafuse line of filaments for FFF 3D printing not only contains metallic filaments but also standard, engineering, flexible, reinforced, high temperature and support filaments. Among the standard materials is the Ultrafuse ABS filament available in 9 colors in spools of 750 g and both 1.75 mm and 2.85 mm diameters. The Ultrafuse ABS filament is manufactured on state-of-the-art computer-controlled machinery, which ensures filament consistency between colors and batches, as well as reliable thermomechanical properties. The Ultrafuse ABS filament is compatible with breakaway supports such as the Ultrafuse HiPS support material.

Part 3d printed with the BASF ABS

Image 1: Part 3D printed with the BASF Ultrafuse ABS filament.

ABS (Acrylonitrile Butadiene Styrene) is a common amorphous thermoplastic polymer and the second most used material in 3D printing, right after PLA. From these two materials, ABS is the go to polymer for engineers and professional applications thanks to its good mechanical resistance (excellent impact strength), relative flexibility, fairly light weight, good thermal and chemical resistance and affordability

Another valuable ABS property is that it can be machined, smoothed with acetone and painted with acrylic and enamel based paints, which makes it especially popular in the automotive industry for the manufacturing of prototypes and functional parts such as instrument panels, door liners, handles or pillar trims.

High speed printing

Furthermore, the ABS Ultrafuse filament is compatible with high printing speeds. In order to create complex structures with this material and a support material, the Xioneer VXL 90 soluble support material or the VXL 111 soluble support material are recommended by the manufacturer. These support materials can be extruded at high speeds as well, which means a smooth and efficient 3D printing. The water solubility of VXL 90/111 makes the post-processing more precise and fast. In the Downloads section a table of compatibilities between the BASF Ultrafuse and Xioneer support filaments can be consulted.

General information

Material ABS
Format 0.75 kg
Density 1.04 g/cm³
Filament diameter 1.75 / 2.85 mm
Filament tolerance - mm
Filament length (Ø1.75 mm, 0.75 kg) ±299.8 m / (Ø2.85 mm, 0.75 kg) ±113 m

Printing properties

Printing temperature 240 - 260 ºC
Print bed temperature 90 - 110 ºC
Chamber temperature -
Cooling fan -
Recommended printing speed 40 - 80 mm/s

Mechanical properties

Elongation at break (ISO 527) 7.4 %
Tensile strength (ISO 527) 36.3 MPa
Tensile modulus 1958 MPa
Flexural strength (ISO 178) 56.6 MPa
Flexural modulus (ISO 178) 1833 MPa
Surface hardness -
Impact strength 19 KJ/m²

Thermal properties

Softening temperature 96 ºC

Other

HS Code 3916.9
Spool diameter (outer) - mm
Spool diameter (inner hole) - mm
Spool width - mm

Like all 3D printing filaments, the Ultrafuse ABS should be stored properly in order to be protected from absorbing moisture. Humidity is the worst enemy of filaments and can lead to extrusion problems and poor print quality. The Ultrafuse ABS filament should be stored in a vacuum sealed bag with a filament drying capsule, in an intelligent filament container before and after printing, and in a filament drying device during printing.

The BASF Ultrafuse ABS filament should be extruded at a temperature of 230-255 ºC and a speed of 30-70 mm/s. A 3D printer with a heated bed is required to 3D print with the Ultrafuse ABS filament, and the temperature of the bed should be set to a minimum of 90 ºC (max 120 ºC).

ABS is a material sensitive to drafts and can warp if printed in uncontrolled environments. It is recommended, although not necessary, to print the Ultrafuse ABS in a closed 3D printer, especially with medium and large parts. To further reduce the chance of warping, the layer fan can be used. Printing ABS on the BuildTak surface or using Kapton Tape, bed adhesion sprays such as DimaFix or 3DLac, or adhesive glue, for example 3DLac Stick or Magigoo, can also significantly improve adhesion and reduce warping with the Ultrafuse ABS.

Featured properties

Printing temperature
240 - 260 ºC
Filament diameter
1.75 / 2.85 mm
High speed compatible
Yes
Density
1.04 g/cm³
