Mechanical elements for Raise3D printers

RAISE-MEC-E2CF-PASS-GEAR-KIT
15.99 € 15.99 €
Tax excl.
Type
Quantity

Do you need more than 1 units?
Please, contact us.

In stock 1 units available for immediate shipping.
units available for shipping in 0 - 0 days Available for shipment within 0 - 0 days

Product temporarily out of stock with these characteristics. Select another combination.

Product temporarily out of stock with these characteristics. Select another combination.

We notify you when it will be available:

Approximate delivery date: Tuesday 26 November
Available

Raise3D 3D printers are composed of multiple mechanical elements that suffer wear during printing, some of them are for example bearings used in the extruder, couplers to join shafts, gears, shafts, positioners, adjusting screws, etc. All of them are essential for efficient and accurate operation of Raise3D 3D printers.

In the following image you can see the filament guide gears and the filament guide piece that goes inside the extruder ([S]5.02.07024A02).

The filament guiding gears and the filament conductor part

Image 1: The filament guiding gears and the filament conductor part. Source: Raise3D.

Another component with wear is the linear bearing in the base of the Raise3D E2 3D printer (E2 Box-type Slider [S]5.08.07007A01), as can be seen in the following image:

The linear bearing of the base of the Raise3D E2 3D printer

Image 2: The linear bearing of the base of the Raise3D E2 3D printer. Source: Raise3D.

The complete list of mechanical elements is as follows:

Compatibility (series) SKU RAISE3D EAN Raise3D product description REFERENCE
Pro3 [S]5.08.12001A01 6970240724025 Extruder Bearings RAISE-MEC-PRO3-EXT-BEAR
E2 & E2CF [S]5.08.07007A01 6970240727514 E2 Box-type Slider RAISE-MEC-E2-TYPE-SLIDER-BASE
N & Pro2 & Pro3 [S]5.08.01001A01 6970240721611 Coupler RAISE-MEC-PRO23-COUPLER
E2 & E2CF [S]5.08.00002 6970240727842 Flange Bearing RAISE-MEC-E2.E2CF-FLANGE-BEARING
Pro2 & Pro3 [S]5.05.05010A01 6970240724339 Thumb Screw RAISE-MEC-PRO23-THUMB-SCREW
Pro2 [S]5.03.05003A01 6970240721642 Pro2 Y Axis Position Limit Trigger RAISE-MEC-PRO2-Y-AXIS-POLIM-TRIG
Pro2 [S]5.03.05002A01 6970240721659 Pro2 X Axis Position Limit Trigger RAISE-MEC-PRO2-X-AXIS-POLIM-TRIG
E2CF [S]5.02.12042A01 6970240724247 E2CF Flexible filament tube RAISE-MEC-E2CF-FLEX-FIL-TUBE
E2CF [S]5.02.12035A01 6970240724230 E2CF 0566 Driven Gear RAISE-MEC-E2CF-DRIVEN-GEAR
E2 & E2CF [S]5.02.07067A01 6970240727460 E2 Y Axis Shaft RAISE-MEC-E2.E2CF-Y-AXIS-SHAFT
E2 [S]5.02.07025A03 6970240727347 Driven Gear RAISE-MEC-E2-DRIVEN-GEAR
E2 [S]5.02.07024A02 6970240728856 E2 Flexible Filament Tube RAISE-MEC-E2-FLEX-FIL-TUBE
E2 & E2CF [S]5.02.07007A01 6970240722779 E2 Z Axis Shaft RAISE-MEC-E2.E2CF-Z-AXIS-SHAFT
Pro2 [S]5.02.06004A01 6970240721734 Pro2 Nozzle Lifting Driving Gear RAISE-MEC-PRO2-NOZZ-LIFT-DRIVEN
Pro2 [S]5.02.05059A01 6970240721437 Extruder Carriage RAISE-MEC-PRO2-EXT-CARRIAGE
N & Pro2 [S]5.02.00165 6970240721161 Coupling RAISE-MEC-PRO2-QUICK-COUPLER
N & Pro2 [S]5.02.00164 6970240727323 X Axis Sliding Block 8/12*30MM RAISE-MEC-PRO2-X-AXIS-BLOCK-812
N & Pro2 [S]5.02.00163 6970240722557 X Axis Sliding Block RAISE-MEC-PRO2-X-SLIDING-BLOCK
N & Pro2 [S]5.02.00162 6970240722540 Y Axis Sliding Block RAISE-MEC-PRO2-Y-SLIDING-BLOCK
N & Pro2 & Pro3 [S]5.02.00135 6970240721468 Crossing Shaft RAISE-MEC-PRO23-CROSSING-SHAFT
N & Pro2 & Pro3 [S]5.02.00134 6970240721390 Left Shaft RAISE-MEC-PRO23-LEFT-SHAFT
N & Pro2 & Pro3 [S]5.02.00133 6970240721604 Rear Shaft RAISE-MEC-PRO23-REAR-SHAFT
N & Pro2 & Pro3 [S]5.02.00132 6970240721475 Right Shaft RAISE-MEC-PRO23-RIGHT-SHAFT
N & Pro2 & Pro3 [S]5.02.00131 6970240721598 Front Shaft RAISE-MEC-PRO23-FRONT-SHAFT
Pro2 & Pro3 [S]5.02.00107 6970240728849 Position Limiter #3 RAISE-MEC-PRO23-POS-LIM-3
Pro2 & Pro3 [S]5.02.00106 6970240728801 Position Limiter #2 RAISE-MEC-PRO23-POS-LIM-2
Pro2 & Pro3 [S]5.02.00105 6970240728832 Position Limiter #1 RAISE-MEC-PRO23-POS-LIM-1
E2 & E2CF [S]3.01.1.999.041A01 6970240727811 Hex Wrench Combo RAISE-MEC-E2.E2CF-HEX-WRENCH
Pro2 [S]3.01.1.999.035A01 6970240722519 heated bed adjustment screws RAISE-MEC-PRO2-HEATB-ADJ-SCREW
Pro2 [S]3.01.1.999.023A01 6970240721949 Pro2 Accessory Box Kits RAISE-MEC-PRO2-ACC-BOX
E2CF [S]3.01.1.022.033A01 6970240727880 Passive Gear Kit RAISE-MEC-E2CF-PASS-GEAR-KIT
Pro2 [S]3.01.1.016.002A01 6970240721666 Pro2 Z Axis Position Limit Trigger Assembly RAISE-MEC-PRO2-Z-AXIS-POLIM-TRIG
Pro2 & Pro3 [S]5.02.14013A01 6970240728382 Pro3 Series Extruder Carrier RAISE-MEC-PRO23-CARRIER
Table 1: Compatibility of the different mechanical elements with the Raise3D printer series. Source: Raise3D.
