Raise3D ESD Resin

RS-RAISE-ESD-BLACK-1KG
108.35 € 108.35 €
Tax excl.
Format
Colour
Quantity

In stock 0 units available for immediate shipping.
units available for shipping in 7 - 10 days
Available for shipment within 7 - 10 days

Product temporarily out of stock with these characteristics. Select another combination.

Product temporarily out of stock with these characteristics. Select another combination.

We notify you when it will be available:

Approximate delivery date: Wednesday 4 June - Monday 9 June

ESD Black Resin is an advanced technical material for 3D printing with electrostatic dissipative (ESD) properties, ideal for industrial applications requiring electrostatic safety. Designed to prevent static electricity buildup, this resin from Raise3D protects sensitive electronic circuits, prevents sparks, and reduces the risk of explosions in environments with fine dust or flammable materials.

This ESD resin for Raise3D printers is formulated to dissipate electric charges in a controlled manner, maintaining a specific surface resistivity (between 10⁵ and 10⁸ ohms per square) that prevents damage to electronic components, electromagnetic interference, and ignition hazards. It is widely used in industries such as electronics, automotive, aerospace, robotics, and advanced manufacturing, where an electrostatic discharge-free environment is essential.

Video 1: Raise3D DF2+ resin 3D printer presentation.

This resin from Raise3D combines outstanding mechanical properties, such as a 3.0 GPa elastic modulus and a 68 MPa tensile strength, with high dimensional accuracy and surface quality, allowing the production of complex, functional, and durable parts. It is ideal for manufacturing electronic housings, handling trays, technical tooling, industrial prototypes, sensor mounts, and connector enclosures.

Optimized for resin 3D printers, the ESD Black offers an efficient, precise, and safe solution for critical environments where electrostatic dissipation and mechanical resistance are essential.

Raise3D resin 3D printerPhoto 1: Raise3D DF2 resin 3D printer. Source: Raise3D

General information

Manufacturer Raise3D
Material Photopolymer
Format 1 Kg
Technology DLP/LCD
Wavelength 405 nm
Viscosity (ASTM D7867 ASTM D7867 1267 cps@25°C) 1267

Printing properties

Layer exposure time 7

Curing and washing properties

Washing time - min
Curing time 10 min

Mechanical properties (uncured / cured)

Izod impact strength (ASTM D256) 28.0 KJ/m²
Elongation at break (ASTM D638) 6 %
Tensile strength (ASTM D638) 68 MPa
Tensile modulus (ASTM D638) 3000 MPa
Flexural strength (ASTM D790) 126 MPa
Flexural modulus (ASTM D790) 3000 MPa
Surface hardness (ASTM D2240 Shore D) 85 D

Thermal properties (uncured / cured)

Softening temperature (ASTM D648 @1.82 MPa/264 psi) 53 ºC

Other

HS Code 2916.1

Featured properties

Technology
DLP/LCD
ESD
Yes
