FilaWarmer - Metallic filament heater

FILAWARMER-TVF
88.00 € 88.00 €
Tax excl.
Quantity

In stock 10 units available for immediate shipping.
units available for shipping in 0 - 0 days
Available for shipment within 0 - 0 days

Product temporarily out of stock with these characteristics. Select another combination.

Product temporarily out of stock with these characteristics. Select another combination.

We notify you when it will be available:

Approximate delivery date: Friday 22 November

To achieve a successful 3D printing, all elements and materials must be in the optimal conditions. One of the most important conditions when printing Filamet ™ is that the filament is completely straight before entering the extruder. Naturally, the Filamet ™ has the same curvature of the coil due to the plastic surrounding the metal. To eliminate that curvature, The Virtual Foundry features FilaWarmer, a device formed by a cylindrical that heats the filament and a temperature controller. As the material passes through the heating cylinder, it loses its curvature, increases flexibility and reduces tensile strength, thus preventing breakage and facilitating printing.

FilaWarmer is designed to be used with filaments of any diameter (1.75 mm or 2.85 mm) and in 3D printers with direct type or bowden extruder. Once the filament passes through the heating cylinder, it reaches the ideal flexibility so that the material is flexible enough not to split (fragile breakage) but without complicating the printing configuration, as is the case with flexible filaments in 3D printers with extruder Bowden type.

FilaWarmer heater cylinder

The FilaWarmer is delivered programmed at 60 °C, ideal temperature for Filamet™. In the case of printing parts with Filamet™ tungsten, the use of FilaWarmer is not recommended.

To achieve the best results, it is essential to correctly place the coil and FilaWamer with respect to the 3D printer. The heating cylinder should be placed as close as possible to the filament coil, always vertically, and the outlet hole of the heating cylinder must be aligned with the inlet hole of the extruder. This minimizes friction in the extruder to avoid possible errors during printing and improve the final result of the manufactured part.

FilaWarmer

General information

Manufacturer The Virtual Foundry
Filament diameter 1.75 / 2.85 mm
Maximum working temperature 100 ºC

Other

HS Code 8514.40

Other information

Package Contents*

  • 1x Heating cylinder
  • 1x Type A electrical connector (American)

* Does not include an adapter for type C electrical connector (European).

FilaWamer is a device designed to heat the Filamet™ filament in a controlled manner before it is fed through the extruder.

Filamet™Temperature (ºC)
316L stainless steel
Copper
Bronze
High carbon steel-
6061 aluminum
Tungsten
Table 1: Compatibility of FilaWarmer with Filamet filaments. Source: The Virtual Foundry.

The heating cylinder should be positioned vertically, with the inlet as close as possible to the filament spool and the outlet aligned with the extruder inlet hole, just like shown in the video provided by the manufacturer.

Video 1: How to setup Filawarmer. Source: The Virtual Foundry.

The Virtual Foundry recommends hanging the heating cylinder to allow the coil to rotate freely.
